XM-PT530W-30W 3MP WIFI Bullet Camera

Regular price $24.00 USD
Regular price Sale price $24.00 USD
Shipping calculated at checkout.

Customization

Customized logo Min. Order: 20 Pieces
Customized Packing Min. Order: 20 Pieces


Specification

Model Model Type 3.0MP WIFI Camera
Model No. XM-PT530W-30W
System System structure Embedded Linux real-time operating system
Processor AK3919E_V330
Sensor F37 1/3 "CMOS Sensor, Color: 0.1 Lux, Black/White: 0.01 Lux
Image output Main stream: 2304*1296@15fps; Substream: 640x360@15fps
Video processing H.264/H.265 video encoding, supporting double bit stream
Noise reduction 2 d / 3 d noise reduction
Shutter Automatic shutter
Lens 3.6mm hd lens
Night vision IR-CUT,Infrared night vision, color filter automatically switch
light distance Infrared 15m (6 infrared light)
Audio Audio processing G.711A,two way audio
Network Network interface One RJ45 Ethernet port,10/100M auto-sensing
WIFI antenna interface 2.4g dual WIFI antenna
Alarm   Human detection, motion detection, smart AI alarm
  APP push, voice alarm, video recording, capture pictures
Video Video mode Timing video, event video
Playback mode Event playback, time playback
PTZ   pan 180 degree
  Human tracking, guard position
Storage Storage Local TF card, up to 128G; Cloud storage
  ONVIF support
Cell phone monitoring Mobile phone monitoring (iOS, Android)
Power consumption ≤6W
power DC12V
Material ABS
Reset Support one-button reset function
Work environment Temperature -20℃ to +55℃
Humidity 30% to 80% RH
Package Size
Weight



Features

· 180 degrees horizontally rotatable via mobile app

·High-definition two-way audio

· 3MP HD video recording provides superior quality for reviewing fine details in heightened resolution

· Infrared cut filter ensures accurate color representation

· Night vision range up to 100ft (31m) in total darkness conditions

· Weatherproof for outdoor & indoor installation (IP66 Rated)

· Get Instant email alerts when motion is detected

· Support up to 128GB SD Card

· Support FTP motion detection video upload

If you need Power Extension Cable to extend this power cable, plese click here to buy 5m or 10m Power Extension Cable

Easy Installation

Adjust the camera angle freely without screwdriver.

Rotating Control

The rotation angle of the camera with a rotating motor can reach 180°,You can remotely adjust the camera Angle on your phone,Make the camera's field of view wider.

Humanoid Motion Detect Alarm

With Humanoid Motion Detection Technology, it will be sent alert messages when pushed alarm to local App & View something on video when playback

3MP HD Video Resolution

For protecting the things that matter most, having a security camera with 2304*1296 HD resolution is vital.

Humanoid Motion Detect Alarm

With Humanoid Motion Detection Technology, it will be sent alert messages when pushed alarm to local App & View something on video when playback

Customize Zones for More Detail to Detect

With customized-zones, you can choose specific aeras of what you need to take care, it's very great design for you to save HDD storage.

Two-Way Audio

Two-way audio feature allows you to listen and speak through the camera.With microphone and speaker, you can better understand the details that are happening

Clear Day light and Night Vision

Eqith IR-CUT Arrays to view far enough, everything is sharp .Always keep eyes to protect your family in good condition.

IP66 Waterproof

IP66 waterproof.Professional waterproof design,Outdoor waterproof, Good sealing,No need to worry about rain.

Built-in SD Card Slot

Easy to install sd card,The recording time depends on the SD Card you install,check below recording time for reference :

32GB :7- 8 Days 64GB :15-16 Days

Local or Remote View from Multiple Devices

Local Viewing: No Network needed, just connect the system to a monitor via HDMI/VGA port
Remote Viewing: Download the ''Eseecloud''Smart app on your smartphone (iOS or Android)

Two Ways To Connect To The Internet

The camera can be connected to the router via wifi or a network cable, and you can easily choose a convenient way to connect to the Internet according to the scene.

APP Connection

Product Details



Company Profile



1:What is your company’s competitive advantage?

Tinosec is a professional manufacturer of R&D, Production, and Marketing (3 in 1)
in security camera system and solar light camera more than 10 years.
A.Service:OEM/ODM orders are welcomed!
B.Certificates:RoHs,FCC,CE,EMC,PSE and ect.

2:what services can we provide?
Accepted Delivery Terms: EXW,DAP,DDP;
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union;
Language Spoken:English,Chinese,Japanese,Russian

3:When can I get the quotation?
We usually quote within 1 hours after getting your inquiry. If you are very urgent, please contact us by phone, email, Skype, WhatsApp or Wechat. You can find all our sales’s contact information in this page

4:How to provide you a good market suggestion?
We provide you an accurate and comprehensive marketing suggestion in accordance with alibaba periodical big data, google big data, our company data, in combination with our experience.

5:How to proceed LOGO print order?
1) send us the logo files, once receiving your payment(large order 30%), we will arrange to design the logo;
2) after received your confirmation of the logo, we will do sample and send it to you check;
3) if you confirm the sample is ok, we will produce the mass;
4) once ready, please pay the rest payment and we will send out goods and tell you the tracking number;

6:What is the guarantee of our products and how about the returns?
1) 12 months warranty, low-value consumption goods is not within the scope of the warranty;
2) Warranty service will be honored if the damage is not caused by human;
3) Please send back the defective goods within the warranty period, we will repair them or send you new free;
4) If there are only several pieces accessory(the fee is less or around shipping fee) are damaged, please send us some pictures and videos about the detail problem. Once confirmed the problem, we will send you free new goods together with your next order.

7:What shipping method can i choose? How about the shipping time?
For EU / US order, by local express about 1-3 days.
For small order, by air express like DHL, UPS, TNT, FedEx ,Aramex and etc, about 3-7days.
For big order, by air about 7-12 days, by sea about 15-35 days.

8:OEM/ODM available
* Customized camera housing / material. * Customized color box / Blister pack. * Any of your own idea we
can help you to design and put it into protection
