XM-PT530W-30W 3MP WIFI Bullet Camera

$24.00 USD
$24.00 USD
Shipping calculated at checkout.

Customization

Customized logo Min. Order: 20 Pieces
Customized Packing Min. Order: 20 Pieces


Specification

Model Model Type 3.0MP WIFI Camera
Model No. XM-PT530W-30W
System System structure Embedded Linux real-time operating system
Processor AK3919E_V330
Sensor F37 1/3 "CMOS Sensor, Color: 0.1 Lux, Black/White: 0.01 Lux
Image output Main stream: 2304*1296@15fps; Substream: 640x360@15fps
Video processing H.264/H.265 video encoding, supporting double bit stream
Noise reduction 2 d / 3 d noise reduction
Shutter Automatic shutter
Lens 3.6mm hd lens
Night vision IR-CUT，Infrared night vision, color filter automatically switch
light distance Infrared 15m (6 infrared light)
Audio Audio processing G.711A，two way audio
Network Network interface One RJ45 Ethernet port,10/100M auto-sensing
WIFI antenna interface 2.4g dual WIFI antenna
Alarm 　 Human detection, motion detection, smart AI alarm
　 APP push, voice alarm, video recording, capture pictures
Video Video mode Timing video, event video
Playback mode Event playback, time playback
PTZ 　 pan 180 degree
　 Human tracking, guard position
Storage Storage Local TF card, up to 128G; Cloud storage
　 ONVIF support
Cell phone monitoring Mobile phone monitoring (iOS, Android)
Power consumption ≤6W
power DC12V
Material ABS
Reset Support one-button reset function
Work environment Temperature -20℃ to +55℃
Humidity 30% to 80% RH
Package Size 　
Weight 　



Features

· 180 degrees horizontally rotatable via mobile app

·High-definition two-way audio

· 3MP HD video recording provides superior quality for reviewing fine details in heightened resolution

· Infrared cut filter ensures accurate color representation

· Night vision range up to 100ft (31m) in total darkness conditions

· Weatherproof for outdoor & indoor installation (IP66 Rated)

· Get Instant email alerts when motion is detected

· Support up to 128GB SD Card

· Support FTP motion detection video upload

If you need Power Extension Cable to extend this power cable, plese click here to buy 5m or 10m Power Extension Cable

Easy Installation

Adjust the camera angle freely without screwdriver.

Rotating Control

The rotation angle of the camera with a rotating motor can reach 180°，You can remotely adjust the camera Angle on your phone，Make the camera's field of view wider.

Humanoid Motion Detect Alarm

With Humanoid Motion Detection Technology, it will be sent alert messages when pushed alarm to local App & View something on video when playback

3MP HD Video Resolution

For protecting the things that matter most, having a security camera with 2304*1296 HD resolution is vital.

Humanoid Motion Detect Alarm

With Humanoid Motion Detection Technology, it will be sent alert messages when pushed alarm to local App & View something on video when playback

Customize Zones for More Detail to Detect

With customized-zones, you can choose specific aeras of what you need to take care, it's very great design for you to save HDD storage.

Two-Way Audio

Two-way audio feature allows you to listen and speak through the camera.With microphone and speaker, you can better understand the details that are happening

Clear Day light and Night Vision

Eqith IR-CUT Arrays to view far enough, everything is sharp .Always keep eyes to protect your family in good condition.

IP66 Waterproof

IP66 waterproof.Professional waterproof design,Outdoor waterproof, Good sealing,No need to worry about rain.

Built-in SD Card Slot

Easy to install sd card，The recording time depends on the SD Card you install,check below recording time for reference :

32GB :7- 8 Days 64GB :15-16 Days

Local or Remote View from Multiple Devices

Local Viewing: No Network needed, just connect the system to a monitor via HDMI/VGA port
Remote Viewing: Download the ''Eseecloud''Smart app on your smartphone (iOS or Android)

Two Ways To Connect To The Internet

The camera can be connected to the router via wifi or a network cable, and you can easily choose a convenient way to connect to the Internet according to the scene.

APP Connection
